10G BIDI SFP+ 60KM
10Gb/s SFP+ Tx1270nm/Rx1330nm
60km Bi-directional Transceiver
Temperature Control
Lower CO=onsumption
Plug & Play
Ensured Compatibility
Temperature Control
Low Power Consumption
Plug & Play
Ensured Compatability
Product Features
The SFP+ package with LC connector features a 1270nm (1330nm) DFB laser and PIN-TIA photodetector, supporting up to 60km transmission on SMF and data links up to 11.3Gbps. It supports optional dual CDR in TX and RX channels, operates on a +3.3V single power supply with power dissipation under 1.5W, and offers a 2-wire interface with integrated digital diagnostic monitoring.
Sub Series
- 10G BIDI SFP+ 40KM
- 10Gb/s SFP+ Tx1270nm/Rx1330nm
- 40km Bi-directional Transceiver
Applications:
- Ethernet
- Telecom
- Fiber Channel
Absolute Maximum Ratings
The parameters include a storage temperature range from -40°C to +85°C (Tst) and a supply voltage range from -0.3V to +4.0V (VCC). The operating relative humidity (RH) is specified between 5% and 95%.
Operation Environment
The operating environment parameters specify an operating case temperature (TC) ranging from -5°C to +70°C for commercial use and -40°C to +85°C for industrial use. The supply voltage (VCC) ranges from 3.15V to 3.45V, with a power dissipation of 1.5W and a supported data rate of up to 10.3125Gbps.
Electrical Interface Characteristics
The electrical interface characteristics, defined at an ambient operating temperature of 0°C to +70°C with Vcc = 3.3V, include transmitter parameters such as a differential line input impedance (Zin) of 90–110 Ohm, differential data input swing (Vin) of 180–700 mV, transmit disable voltage of 2V–Vcc, transmit enable voltage of -0.3–0.8V, transmit fault assert of 2.4V–Vcc, and transmit fault deassert of -0.3–0.8V.
Ethernet
Telecom
Fiber Channel
Download Data Sheet
